The Purpose: The Flexible Box Layout Module, makes it easier to design a flexible responsive layout structure without using float or positioning. It's a more efficient way to layout, align, and distribute space among items in a container.

/* This creates a flex container and all elements inside this
   container become 'flex items'. */
.flex-container {
    display: flex;
}

Terminology

• Flex container: refers to the element that has the display: flex property applied to it.
• Flex items: refers to the elements that are contained within a flex-container.
• Main axis: By default, the main axis direction goes from left to right. You can change the direction of the main axis with flex-direction.
• Cross axis: is the opposite of whatever the main axis is. By default, the direction of it goes from top to bottom.

💡 The main axis and cross axis will always be perpendicular to one another.

Container Properties

1. flex-direction
2. flex-wrap
3. justify-content
4. align-items
5. align-content

1) flex-direction

• Allows us to specify how flex items are placed within a flex container. It defines the main axis and its direction. Default is flex-direction: row.
• When flex-direction: row is applied, the main axis is horizontal.
• When flex-direction: column is applied, the main axis is vertical.
• Sandbox Examples 🏗️

2) flex-wrap

• Allows us to specify if the items in a flex container (flex items) are forced into a single line or can be wrapped into multiple lines. Default is flex-wrap: nowrap. This applies to both rows and columns (although columns are less common and look a little wonky.)
• If flex-wrap is not defined on a container and you have elements with large widths, the flexbox container will ignore them and make it so that everything fits on a single line. The container will make the items as big as they can without making them wrap.
• Sandbox Examples 🏗️

3) justify-content

• Allows us to specify how the space inside of a flex container should be distributed between the different items along the main axis.
• Default is justify-content: flex-start
• Sandbox Examples 🏗️

4) align-items

• Defines how space is distributed between items in flex container along the cross axis. Default is align-items: stretch.
• justify-content and align-items do the same things, just on different axes.
• Sandbox Examples 🏗️

5) align-content

• Defines how space is distributed between rows in a flex container along the cross axis. Default is align-content: stretch.
• Sandbox Examples 🏗️

Flex-Item Properties

1. align-self
2. order
3. flex-basis
4. flex-shrink
5. flex-grow
6. flex

1) align-self

• Allows you to override align-items on an individual flex item. Default is align-self: auto.
• It’s very similar to align-items. While align-items encompasses all flex items in a container, align-self grabs an individual flex item and applies the property to that individual item only along the cross axis.
• Sandbox Examples 🏗️

2) order

• Specifies the order used to layout items in their flex container.
• By default, all items have an order of 0.
• order only affects the visual order of items and not their logical order. Due to this, it could cause accessibility issues with screen readers since it creates a disconnect between what the user sees and the actual DOM order.

3) flex-basis

• Specifies the ideal size of a flex item before it’s placed into a flex-container.
• It’s sort of like width when you are working with rows and height when you’re working with columns.
  • For example, If you were to have a row with a set width and flex-basis, the flex-basis value would get precedence over the width since it’s the “ideal size.”
  • The Difference between width and flex-basis

4) flex-shrink

• Dictates how items should shrink when there is not enough space in a container. By default, flex-shrink: 1 is applied and all items will shrink at the same rate.
• The math for flex-shrink is different from flex-grow.
• This property can be useful for things like navigation bars where you want things to shrink in a particular way.
• MDN - flex-shrink

5) flex-grow

• Dictates how the unused space (if any) should be spread amongst flex items. By default, flex-grow: 0 is applied and all items will grow at the same rate.
• When you assign a number to flex-grow, all items will evenly divide the unused space amongst themselves.
• Article on flex-grow

6) flex

• Defines how a flex item will grow or shrink to fit the available space in a container. It is a shorthand property for flex-grow, flex-shrink, and flex-basis.
  • Syntax: flex: <flex-grow> <flex-shrink> <flex-basis>
• MDN - CSS flex Property

References

• Udemy Course - The Advanced Web Developer Bootcamp
• W3Schools - CSS Flexbox
• In-depth Tutorial on Flexbox by Colt Steele
